Cryogenic Top-Entry Ball Valve

No.CRYO-TE
HEVC cryogenic top-entry ball valves place maintenance access above the valve body for LNG equipment and low-temperature process piping. Austenitic stainless-steel construction and quarter-turn isolation combine with the top-entry arrangement where access to internal components is an important part of installation and maintenance planning.
Technical Specifications Product Scope
Size 1/2–4 in. (DN15–DN100)
Pressure Rating ASME Class 150–1500 (PN16–PN250)
Temperature Down to -196°C
Body Materials Austenitic stainless steel
Ends RF or BW
Actuation Manual, pneumatic, electric or hydraulic
Download
View all downloads
  • cryogenic top-entry ball valve for LNG

Description

Design & Construction

  • Top-entry access

    Access from the top of the body supports maintenance planning for valve internals.

  • Quarter-turn isolation

    Ball-valve operation provides on/off shutoff for cryogenic process lines.

  • Cryogenic construction

    Austenitic stainless-steel construction forms the low-temperature body-material platform.

Typical Duty / Applications

  • LNG equipment

    Isolation in liquefaction and associated low-temperature equipment.

  • Cryogenic loading systems

    Shutoff points in transfer and loading piping.

  • LPG and air separation

    Low-temperature isolation in LPG and air-separation processes.

Testing & Documentation

  • Inspection and testing

    Material verification, shell-pressure testing, seat-leakage testing and operating checks form the inspection scope.

  • Technical documents

    Valve drawings, datasheets, material records, inspection reports and operating-unit documentation support technical coordination.
